| General Information | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 38 | 41 |
| Power Rating (kW) | 30 | 33 |
| Frequency (Hz) | 50 | |
| Engine Model | 4BT3.9-G1 | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (customizable) | |
| Fuel Tank Capacity Operating Time | ≥ 8h @ 75% load | |
| Model | BC41 (Open type) | BC41S (Silent type) |
|---|---|---|
| Length (mm) | 1600 | 2250 |
| Width (mm) | 720 | 930 |
| Height (mm) | 1300 | 1220 |
| Tank Capacity (L) | 69 | 69 |
| Engine Model & Manufacturer | 4BT3.9-G1 (Cummins) |
| Number of Cylinders | 4 |
| Cylinder Arrangement | In-line |
| Cycle | Four stroke |
| Aspiration | Turbocharged |
| Bore x Stroke | 102 x 120 mm |
| Displacement | 3.9 L |
| Compression Ratio | 17.3:1 |
| Prime Power/Speed | 36 kW/1500 rpm |
| Standby Power/Speed | 40 kW/1500 rpm |
| Fuel System | BYC A/RSV Mechanical |
| Cooling System | Force Water Cooling Cycle |
| Total Lubrication System Capacity | 10.9 L |
| Coolant Capacity (engine only) | 7.2 L |
| Fuel Consumption (100% load) | 229 g/kWh @1500 rpm |
| Alternator Brand | BOBIG |
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-184H |
| Alternator Rated Power | 30kw/38kva |
| Rated Voltage | 230v/400v |
| Rated Frequency | 50hz |
| Connecting Type | 3 Phase and 4 W |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper |
| Insulation Class | H class |
| Voltage Regulation, Steady State | ≤±1% |
