| General Information | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 113 | 124 |
| Power Rating (kW) | 90 | 99 |
| Frequency (Hz) | 50 | |
| Engine Model | 4BTAA3.9-G3 | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (Customizable) | |
| Fuel Tank Capacity Operating Time | ≥ 8h @ 75% load | |
| Model | BC124 (Open Type) | BC124S (Silent Type) |
|---|---|---|
| Length (mm) | 2120 | 2850 |
| Width (mm) | 850 | 1040 |
| Height (mm) | 1400 | 1430 |
| Tank Capacity (L) | 207 | 207 |
| Engine Model & Manufacturer | 4BTAA3.9-G3 (Cummins) |
| Number of Cylinders | 4 |
| Cylinder Arrangement | In-line |
| Cycle | Four Stroke |
| Aspiration | Turbocharged & Air-Air Intercooler |
| Bore x Stroke | 102 x 120 mm |
| Displacement | 3.9 L |
| Compression Ratio | 18.0:1 |
| Fuel System | WF PW Pump / Electronic Governor |
| Cooling System | Force Water Cooling Cycle |
| Alternator Brand | BOBIG |
| Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-274D |
| Protection Grade | IP23 |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating |
| Insulation Class | H class |
