| General information | Prime power | Standby power |
|---|---|---|
| Rated Power (kVA) | 625 | 688 |
| Power Rating (kW) | 500 | 550 |
| Frequency (Hz) | 50 | |
| Engine Model | DP180LB | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated voltage (V) | 400/230 (According to customer requirements) | |
| Fuel tank capacity operating time | ≥ 8h @ 75% load | |
| Dimension and Weight | BDO688 | BDO688S |
|---|---|---|
| Type | Open type | Silent type |
| Length (L) mm | 3800 | 4560 |
| Width (W) mm | 1740 | 1900 |
| Height (H) mm | 2745 | 2480 |
| Tank capacity (L) | 1150 | 1150 |
| Engine model & manufacturer | DP180LB(DOOSAN) |
|---|---|
| Engine Model | DP180LB |
| Engine Type | Diesel, water cooled, Turbo charged & intercooled |
| Bore x stroke | 128 × 142mm |
| Displacement | 18.3 liters |
| Cylinders and Arrangement | Cast iron, 10 cylinder, Vee-Type |
| Battery charging alternator | 27.5V x 45A alternator |
| Starting voltage | 24V |
| Fuel System | Mechanical Injection Pump |
| Fuel Filter | Full flow, cartridge type with water drain valve |
| Lube oil filter type(s) | Full flow, cartridge type |
| Lube oil capacity (l) | Max. 34 liters , Min. 23 liters |
| Flywheel dimensions | Clutch No. 14 M |
| Dry weight | 1250kg (engine only) |
| Dimension (LxWxH) | 1592 ×1389× 1223 mm |
| Alternator Brand | BOBIG |
|---|---|
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-354E |
| Alternator Rated Power | 500kw/625kva |
| Rated voltage (V) | 230v/400v |
| Rated frequency | 50hz |
| Connecting Type | 3 Phase and 4 W |
| Number of Bearing | 1 |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Exciter Type | Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper |
| Insulation Class | H class |
| Telephone Influence Factor (TIF) | ≤50 |
| THF | ≤2% |
| Voltage Regulation, Steady State | ≤±1% |
| Transient State Voltage | ≤-15%～+20% |
